Profile configuration: frame structure depth is 75mm, profile wall thickness is 1.65mm
Energy-saving configuration: 35.3mm high-performance cavity heat insulation strip (PA66+GF25)
Rubber strip configuration: TPE environmental protection tasteless high elastic sealing tape
Hardware configuration: Sobinco, Gu, HOPPE, Roto, silvia, gith
Color: 3D, 4D wood shavings, fluorocarbon, electrophoresis eucalyptus, electrostatic spraying
Screen window configuration: diamond anti - theft screen window, hanging screen window, invisible screen window
Glass configuration :(5 laminated +20A+5) double hollow, 5+9A+5+9A+5 laminated glass
Performance: water tightness: 700Pa, GB/ t7106-2008 class 6
Air tightness: GB/ t7106-2008 class 8
Wind pressure: 5.0Kpa, GB/ t7106-2008, level 9
Sound insulation: Rw(c; (CTR) = 36-2; - 6 db
Insulation: k=1.8(double silver low-e5 +12A+5+12A+5), gbt8484-2008 level 7
